    Product Details:

    Place of Origin: China
    Brand Name: huahan
    Certification: SGS
    Model Number: HP5 Series Mica PIate
    Contact Now
    Detailed Product Description

    Product Code: Muscovite and refractory (HP5)
    Product parameters:
    Muscovite mica paper
    Adhesive: silicone resin
    Mica content (%): = 90%
    Rubber content (%): less than 10%
    Thickness: 0.10 ~ 2 (mm)
    Thickness error (mm):
    Mean mean + / - 0.05
    Each point - + 0.05 - 0.08
    Density (g/cm 3): 1.6-2.4
    Heating reduction (%): less than 1
    The bending strength (kgf/mm 2): more than 18
    The breakdown voltage (KV/mm):>20
    High temperature insulation resistance (M): 200600
    Working temperature: 550 degrees
    Standard size (mm): 1000 x 6001000 x 1200
    Test standards: GB501985, IEC371
    The breakdown voltage is less than or equal to 0.3 mm thickness of the mica plate to be agreed
